1-Way 4.00mm SMD Push-In Screwless Terminal Block 9A 600V
by PTR HARTMANN
SKU 487647
MPN: AK4091/01KD-4.0-WHITE-SMD-R24
Availability:
1480 in stock
Original price
£0.25
-
Original price
£0.25
Original price
£0.25
£0.25
-
£0.25
Current price
£0.25
1 pole SMD terminal block manufactured by PTR HARTMANN, featuring a 4mm pitch and parallel wire entry to the board. The terminal blocks are rated up to 9A, making them suitable for a wide range of PCB applications.
1 pole 4.00mm pitch Push-in connection With lever Reflow soldering Wire entry parallel to the board Material: PPA Rating: 9A 600V Wire size: 24-18AWG Supplied on tape for automatic assembly
Specification
| Back Order Lead Time | 10 Days |
| Colour | White |
| Contact Material | Copper Alloy |
| Current Rating | 9A |
| Housing Material | PPA |
| Mounting Type | PCB Mount |
| Number of Ways | 1 |
| Operating Temperature | -60°C to +105°C |
| Pitch | 4.00mm |
| Termination Method | Spring Lever |
| Voltage Rating | 600VAC |
| Wire Range | 24-18AWG |
