100nF 63V 5mm Polyester Box Capacitor 10% R82DC3100AA50K

100nF 63V polyester capacitor from the R82 series constructed of metallized polyester with radial leads of tinned wire. Radial leads are electrically welded to the contact metal layer on the ends of the capacitor winding. The capacitor is encapsulated with thermosetting resin in a box of material meeting the UL 94V–0 requirements. Typical applications include blocking, coupling, decoupling, timing and oscillator circuits.

Pitch: 5mm

Tolerance: 10%

Self healing

Size: 7.2 x 6.5 x 2.5mm
