10k 6mm Horizontal Preset Trimmer Potentiometer

10k 6mm Horizontal Preset Trimmer Potentiometer

by Switch Electronics
SKU 133062

MPN: 133062

Availability:
1905 in stock
£0.34 - £0.34
£0.34
£0.34
£0.34 - £0.34
£0.34
Cermet trimmer potentiometers with a 210° rotation and 0.1W rated power suitable for horizontal PCB mounting.

  • 10k linear
  • 0.1W rated power
  • Low rotation torque
    • Download Product Data Sheet PDF
    Specification
    Back Order Lead Time 150
    Maximum Voltage 50VDC
    MOQ 5
    Mounting Type PCB
    Operating Temperature -25°C to +70°C
    Pitch 5mm
    Power Rating 0.1W
    Resistance 10KΩ
    Taper Linear
    Termination Type Pin
    Tolerance ±20%
    Total Rotation 210°
