10K Logarithmic Stereo Right Angle PCB 16mm Potentiometer
SKU 481629
MPN: 481629
Availability:
140 in stock
Original price
£0.83
-
Original price
£0.83
Original price
£0.83
£0.83
-
£0.83
Current price
£0.83
10k logarithmic stereo potentiometer featuring right angle PCB contacts and splined 6mm shaft.
10k logarithmic Standard 16mm diameter size 20% tolerance Panel cut-out: 7mm 5mm pitch 15mm shaft length
Specification
| Back Order Lead Time | 45 Days |
| Dimensions | 17mm Diameter |
| Maximum Voltage | 150V |
| Mounting Hole Diameter | 7mm |
| Mounting Type | PCB |
| Operating Temperature | -25°C to +70°C |
| Pitch | 5mm |
| Power Rating | 0.063W |
| Resistance | 10KΩ |
| Shaft Diameter | 6mm |
| Taper | Logarithmic |
| Termination Type | Pin |
| Tolerance | ±20% |
| Total Rotation | 300° |
