10r 10W Aluminium Wirewound Resistor 5%
SKU 483555
MPN:
Availability:
81 in stock
Original price
£1.51
-
Original price
£1.51
Original price
£1.51
£1.51
£1.51
-
£1.51
Current price
£1.51
10r 10W aluminium clad resistors featuring a small package designed for direct heatsink mounting. The resistors are suitable for a wide range of applications including power supplies and audio.
High power to volume Wound to maximise high pulse capability 150V maximum working voltage 5% tolerance Solder terminations Features 2 mounting holes
Specification
| Back Order Lead Time | 45 Days |
| Dimensions | 19 x 21 x 10mm (Length x Width x Height) |
| Maximum Operating Voltage | 150V |
| mpn | 483555 |
| Packaging | Bulk |
| Power Rating | 10W |
| Resistance | 10Ω |
| Temperature Coefficient | ±300ppm/°C |
| Termination | Solder Lug |
| Tolerance | ±5% |
