12V Red illuminated On-Off Toggle Switch SPST
SKU 481748
MPN: 481748
Availability:
88 in stock
Original price
£1.06
-
Original price
£1.06
Original price
£1.06
Inc VAT
£1.06
-
£1.06
Current price
£1.06
Inc VAT
Red illuminated toggle switch featuring On-Off operation and SPST contacts. The switch features quick connect terminals, and is suitable for a wide range of automotive applications.
Operation: On-Off SPST contacts 12V red illumination Rating: 20A 12VDC Panel cut-out: 12mm 6.3mm quick connect terminals Dimensions: 54 x 26.2 x 12mm (Height x Length x Width)
Specification
| Actuation | Latching |
| Back order lead time | 45 Days |
| Contact configuration | SPST |
| Contact rating | 20A 12VDC |
| Current rating | 20A |
| Electrical life | 10,000 Cycles |
| Illuminated | Yes |
| Illumination colour | Red |
| Illumination voltage | 12VDC |
| Mounting style | Panel |
| Number of poles | 1 |
| Number of positions | 2 |
| Operating temperature | -25°C to +85°C |
| Panel cut out | 12mm |
| Switch operation | On-Off |
| Terminal type | Quick Connect |
| Voltage rating | 12VDC |
