12V Subminiature PCB Signal Relay 1A SPDT HFD41

by HongFa
SKU 550019

MPN: HFD41-12-H-S

Availability:
Out of stock
Sold out
Original price £0.97 - Original price £0.97
Original price
£0.97 Inc VAT
£0.97 - £0.97
Current price £0.97 Inc VAT
Sub-miniature sealed signal relay. SPDT contact configuration suitable for PCB mounting.

  • Coil Voltage: 12VDC
  • 1A Contact Rating
  • Coil power: 200mW
  • Sealed construction
  • Maximum Switching Current: 5A
  • 15.7 x 11 x 12mm
  • Maximum switching voltage: 240VAC, 30VDC
  • Specification
    Ambient temperature -25°C to +70°C
    Back order lead time 30 Days
    Coil resistance 700Ω
    Coil voltage 12VDC
    Contact arrangement SPDT
    Maximum continuous voltage 15.6VDC
    Maximum switching current 5A
    Maximum switching voltage 240VAC / 30VDC
    Mounting type PCB
    Number of contacts 5
    Power consumption 0.2W
    Terminal type Through Hole
