15° Polystyrene Tilt Switch - S1267

The TSW 30/60 is a tilt switch with non-mercury contacts, featuring a Nylon 66 case. These switches operate when tilted from the horizontal position. The switch movement required to cause contact change (example off to on) is called the differential angle. Suitable for applications including safety tilt sensing, toy production, security system switch and production automation.

Maximum switching voltage: 60V

Maximum switching current: 0.25A

Maximum switching capacity: 3VA

Differential angle: 15°

Make angle: 10° below horizontal

Break angle: 10° above horizontal

300mm of 2 x round 0.14mm² PVC insulated
