15r 25W Aluminium Wirewound Resistor 5%
SKU 483565
MPN: 483565
Availability:
108 in stock
Original price
$2.59
-
Original price
$2.59
Original price
$2.59
$2.59
$2.59
-
$2.59
Current price
$2.59
15r 25W aluminium clad resistors featuring a small package designed for direct heatsink mounting. The resistors are suitable for a wide range of applications including power supplies and audio.
High power to volume Wound to maximise high pulse capability 200V maximum working voltage 5% tolerance Solder terminations Features 2 mounting holes
Specification
| Back Order Lead Time | 150 |
| Dimensions | 27 x 27 x 13mm (Length x Width x Height) |
| Maximum Operating Voltage | 200V |
| MOQ | 1 |
| Packaging | Bulk |
| Power Rating | 25W |
| Resistance | 15Ω |
| Temperature Coefficient | ±300ppm/°C |
| Termination | Solder Lug |
| Tolerance | ±5% |
