1k 8 Commoned Resistor Network 2%

SKU 552241

MPN:

Availability:
Out of stock
Sold out
Original price £0.14 - Original price £0.14
Original price
£0.14 Inc VAT
£0.14 - £0.14
Current price £0.14 Inc VAT
1k thick film 9-pin commoned resistor network featuring 8 resistors housed in a single in-line package, suitable for high density printed circuit boards.

  • Power: 0.125W
  • Tolerance: ±2%
  • Maximum working voltage: 100V
  • Pitch: 2.54mm
  • Specification
    Back order lead time 5 Days
    Circuit type Commoned
    Maximum operating voltage 100V
    Moq 5
    Mpn RNLA09G0102B0E
    Number of pins 9
    Number of resistors 8
    Operating temperature -55°C to +125°C
    Packaging Cut Tape
    Pitch 2.54mm
    Power rating 0.125W
    Resistance 1KΩ
    Temperature coefficient ±200ppm/°C
    Termination Through Hole
    Tolerance ±2%
