1N5822 Schottky Diode 3A 40V

SKU 402013

MPN: 1N5822

Availability:
4139 in stock
Original price £0.08 - Original price £0.08
Original price
£0.08 Inc VAT
£0.08 - £0.08
Current price £0.08 Inc VAT
Power schottky rectifier diodes with axial leads suitable for low voltage applications.

  • Maximum recurrent peak reverse voltage: 40V
  • Maximum average forward current: 3A
  • 1.2mm diameter leads
  • Supplied on tape packaging
  • Specification
    Average rectified current 3A
    Back order lead time 40 Days
    Body dimensions 9.5 x 5.3mm (Length x Diameter)
    Lead dimensions 25.4 x 1.2mm (Length x Diameter)
    Maximum dc blocking voltage 40V
    Maximum forward voltage 0.525V
    Maximum rms voltage 28V
    Moq 10
    Mounting style Through Hole
    Operating temperature -55°C to 125°C
    Package DO-27
    Packaging Tape
    Peak reverse voltage 40V
    Peak surge current 80A
