2.2nF 100V 5mm Polyester Box Capacitor 10% R82EC1220AA50K

by Kemet
SKU 552111

MPN: R82EC1220AA50K

Availability:
703 in stock
Original price £0.14 - Original price £0.14
Original price
£0.14 Inc VAT
£0.14 - £0.14
Current price £0.14 Inc VAT
2.2nF 100V polyester capacitor from the R82 series constructed of metallized polyester with radial leads of tinned wire. Radial leads are electrically welded to the contact metal layer on the ends of the capacitor winding. The capacitor is encapsulated with thermosetting resin in a box of material meeting the UL 94V–0 requirements. Typical applications include blocking, coupling, decoupling, timing and oscillator circuits.

  • Pitch: 5mm
  • Tolerance: 10%
  • Self healing
  • Size: 7.2 x 6.5 x 2.5mm
  • Specification
    Back order lead time 5 Days
    Capacitance 2.2nF
    Height 6.5mm
    Length 7.2mm
    Material Polyester
    Moq 10
    Mounting style Through Hole
    Operating temperature -55°C to +105°C
    Package Box
    Pitch 5mm
    Tolerance ±10%
    Voltage rating 100V
    Width 2.5mm
