2-Way Screwless 5.00mm Terminal Block
SKU 356092
MPN: 356092
Availability:
597 in stock
Original price
£0.38
-
Original price
£0.38
Original price
£0.38
£0.38
£0.38
-
£0.38
Current price
£0.38
Screwless terminal blocks with lever operated cable clamps to hold the wire securely. The terminal blocks feature a 5mm pitch and can be end-stacked to produce and number of poles.
2 Poles Pitch: 5mm Wire range: 14-20AWG Rated current: 5A Rated voltage: 300V Housing material: PA66 to UL94V-0
Specification
| Back Order Lead Time | 30 Days |
| Colour | Green |
| Contact Material | Tin Plated Bronze |
| Current Rating | 5A |
| Housing Material | PA66 |
| Mounting Type | PCB Mount |
| Number of Ways | 2 |
| Operating Temperature | -45°C to +105°C |
| Pitch | 5.00mm |
| Termination Method | Push Clamp |
| Voltage Rating | 300VAC |
| Wire Range | 14-20AWG |
