2 x 24V 5VA 230V Encapsulated PCB Transformer

2 x 24V 5VA 230V Encapsulated PCB Transformer

by ASN
SKU 451040

MPN: AS4214-E-0500-240-D

Availability:
10 in stock
£3.13 - £3.13
£3.13
£3.13
£3.13 - £3.13
£3.13
PCB encapsulated transformer with a 230V primary voltage and secondary 2x0-24V voltage.

  • Power: 5VA
  • Dual secondary winding
  • Vacuum filled casting
  • Split bobbin design welding
  • Dielectric strength: 4500Vrms
  • Approved by EN61558
    • Download Product Data Sheet PDF
    Specification
    Back Order Lead Time 150
    Dielectric Strength 4500Vrms
    Maximum Ambient Temperature 70°C
    MOQ 1
    Output Current 0.10A
    Power 5VA
    Primary Voltage 230V
    Secondary Voltage 2 x 24V
    Weight 200g
