22K 16mm Linear Stereo Splined Potentiometer
SKU 486682
MPN: 486682
Availability:
40 in stock
Original price
£0.55
-
Original price
£0.55
Original price
£0.55
£0.55
£0.55
-
£0.55
Current price
£0.55
22K linear stereo 16mm potentiometer featuring a 6mm splined shaft and pin terminals, suitable for PCB mounting.
22K linear 6mm diameter splined shaft Standard 16mm diameter size 20% tolerance Panel cut-out: 7mm 5mm pitch 15mm shaft length Power: 125mW
Specification
| Back Order Lead Time | 7 |
| Maximum Voltage | 200V |
| MOQ | 1 |
| Mounting Hole Diameter | 10mm |
| Mounting Type | Panel Mount |
| Operating Temperature | -25°C to +70°C |
| Pitch | 5mm |
| Power Rating | 0.125W |
| Resistance | 22KΩ |
| Shaft Diameter | 6mm |
| Taper | Linear |
| Termination Type | Pin |
| Tolerance | ±20% |
| Total Rotation | 300° |
