24V 2.2A Enclosed Switching Power Supply 50W
SKU 490391
MPN: SE50-20B24
Availability:
11 in stock
Original price
£13.29
-
Original price
£13.29
Original price
£13.29
£13.95
£13.95
-
£13.95
Current price
£13.95
24V enclosed industrial AC-DC power supply featuring a universal input and high efficiency. The power supply features low no load power consumption and excellent reliability. The power supply meets IEC/EN61000-4, CISPR32/EN55032, IEC/UL/EN62368, IEC/EN60335, GB4943,IEC/EN61558 standards widely used in industrial, LED, street light control, electricity, security, telecommunications, smart home applications.
Output voltage: 24V Output current: 2.2A Power: 52.8W Adjustable output voltage range: 21.6-28.8V Input voltage: 85-264VAC, 120-370VDC Efficiency at 230VAC: 89% Output short circuit, over-current, over-voltage protection M3 screw terminals Wire range: 22-12AWG Dimensions: 99.0 x 82.0 x 30.0mm (length x width x height)
Specification
| Back Order Lead Time | 120 Days |
| Input Frequency | 47-63Hz |
| Input Voltage | 85-264VAC, 120-370VDC |
| Maximum Temperature | 70°C |
| MOQ | 1 |
| Output Connector | M3 Screw |
| Output Current | 2.2A |
| Output Voltage | 24VDC |
| Over Current Protection | Yes |
| Over Voltage Protection | Yes |
| Power Rating | 50W |
| Short Circuit Protection | Yes |
