24V Automotive Relay 40A 4-Pin Bracket SPNO
by Meishuo
SKU 480824
MPN: MAH-S-124-A-4
Availability:
765 in stock, ready to be shipped
Original price
£1.38
-
Original price
£1.38
Original price
£1.38
Inc VAT
£1.38
-
£1.38
Current price
£1.38
Inc VAT
24V automotive relay with SPNO contacts and plastic bracket. The relay is sealed providing protection from dust and water, suitable for general purpose automotive applications.
Maximum switching current: 40A Coil voltage: 24VDC Coil power: 1.6W Sealed IP67 construction SPNO contacts Excellent shock and vibration resistance Wide temperature range Body dimensions: 28 x 28 x 25mm
Specification
| Ambient temperature | -40°C to +85°C |
| Coil resistance | 360Ω |
| Coil voltage | 24VDC |
| Contact arrangement | SPNO |
| Maximum continuous voltage | 31.5VDC |
| Maximum switching current | 40A |
| Maximum switching voltage | 80VDC |
| Mounting type | Plug In |
| Number of contacts | 4 |
| Power consumption | 1.6W |
| Terminal type | Quick Connect |
