24V Subminiature PCB Relay DPDT 2A
by AFE
SKU 481877
MPN: BSVR-SS-224L
Availability:
617 in stock
Original price
£1.20
-
Original price
£1.20
Original price
£1.20
£1.20
-
£1.20
Current price
£1.20
24V subminiature relay housed in a sealed compact package suitable for mounting to PCBs. The relay features DPDT contacts and 2A current rating, making it suitable for a wide range of applications with high density PCBs including household appliances.
Coil voltage: 24V Contact configuration: DPDT Contact capacity: 1A 125VAC, 2A 30VDC Maximum current: 2A Maximum voltage: 125VAC, 30VDC Dimensions: 20.1 x 10 x 12mm (Length x Width x Height)
Specification
| Back Order Lead Time | 30 Days |
| Coil Resistance | 2880Ω |
| Coil Voltage | 24VDC |
| Contact Arrangement | DPDT |
| Maximum Continuous Voltage | 31.2VDC |
| Maximum Switching Current | 2A |
| Maximum Switching Voltage | 125VAC / 30VDC |
| Mounting Type | PCB |
| Number of Contacts | 8 |
| Power Consumption | 0.2W |
| Terminal Type | Through Hole |
