24V Subminiature PCB Signal Relay 1A SPDT HFD41
by HongFa
SKU 550020
MPN: HFD41-24-H-S
Availability:
Out of stock
Sold out
Original price
£1.20
-
Original price
£1.20
Original price
£1.20
Inc VAT
£1.20
-
£1.20
Current price
£1.20
Inc VAT
Sub-miniature sealed signal relay. SPDT contact configuration suitable for PCB mounting.
Coil Voltage: 24VDC 1A Contact Rating Coil power: 200mW Sealed construction Maximum Switching Current: 5A 15.7 x 11 x 12mm Maximum switching voltage: 240VAC, 30VDC
Specification
| Ambient temperature | -25°C to +70°C |
| Back order lead time | 30 Days |
| Coil resistance | 2800Ω |
| Coil voltage | 24VDC |
| Contact arrangement | SPDT |
| Maximum continuous voltage | 31.2VDC |
| Maximum switching current | 5A |
| Maximum switching voltage | 240VAC / 30VDC |
| Mounting type | PCB |
| Number of contacts | 5 |
| Power consumption | 0.2W |
| Terminal type | Through Hole |
