2R2 Arcol 25W Aluminium Clad Resistor HS25

by Arcol
SKU 399013

MPN:

Availability:
Only 1 left!
Original price £1.80 - Original price £1.80
Original price
£1.80 Inc VAT
£1.80 - £1.80
Current price £1.80 Inc VAT
Arcol 25W aluminium clad resistors suitable for a wide range of applications where a high power dissipation is required. The resistors have a small package and are designed for direct heatsink mounting.

  • High power to volume
  • Wound to maximise high pulse capability
  • 5% tolerance
  • Solder terminations
  • Features 2 mounting holes
  • Arcol HS series
  • Specification
    Back order lead time 10 Days
    Dimensions 51.0 x 28.0 x 14.6mm (Length x Width x Height)
    Heatsink area 535cm²
    Limiting element voltage 550V
    Mpn HS25 2R2 J
    Operating temperature -55°C to +200°C
    Packaging Bulk
    Power rating 25W
    Resistance 2.2Ω
    Temperature coefficient ±100ppm/°C
    Termination Solder Lug
    Tolerance ±5%
