2R2 Arcol 50W Aluminium Clad Resistor HS50

by Arcol
SKU 399009

MPN:

Availability:
8 in stock
Original price £2.64 - Original price £2.64
Original price
£2.64 Inc VAT
£2.64 - £2.64
Current price £2.64 Inc VAT
Arcol 50W aluminium clad resistors suitable for a wide range of applications where a high power dissipation is required. The resistors have a small package and are designed for direct heatsink mounting.

  • High power to volume
  • Wound to maximise high pulse capability
  • 5% tolerance
  • Solder terminations
  • Features 2 mounting holes
  • Arcol HS series
  • Specification
    Back order lead time 10 Days
    Dimensions 72.5 x 29.7 x 14.8mm (Length x Width x Height)
    Heatsink area 535cm²
    Limiting element voltage 1250V
    Mpn HS50 2R2 J
    Operating temperature -55°C to +200°C
    Packaging Bulk
    Power rating 50W
    Resistance 2.2Ω
    Temperature coefficient ±100ppm/°C
    Termination Solder Lug
    Tolerance ±5%
