2R2 Arcol 50W Aluminium Clad Resistor HS50
by Arcol
SKU 399009
MPN:
Availability:
Only 2 left!
Original price
£3.13
-
Original price
£3.13
Original price
£3.13
£3.13
£3.13
-
£3.13
Current price
£3.13
Arcol 50W aluminium clad resistors suitable for a wide range of applications where a high power dissipation is required. The resistors have a small package and are designed for direct heatsink mounting.
High power to volume Wound to maximise high pulse capability 5% tolerance Solder terminations Features 2 mounting holes Arcol HS series
Specification
| Back Order Lead Time | 10 Days |
| Dimensions | 72.5 x 29.7 x 14.8mm (Length x Width x Height) |
| Heatsink Area | 535cm² |
| Limiting Element Voltage | 1250V |
| mpn | HS50 2R2 J |
| Operating Temperature | -55°C to +200°C |
| Packaging | Bulk |
| Power Rating | 50W |
| Resistance | 2.2Ω |
| Temperature Coefficient | ±100ppm/°C |
| Termination | Solder Lug |
| Tolerance | ±5% |
