3.3V AC-DC 1W Single Output Power Supply VTX-214-001-103
by Vigortronix
SKU 480328
MPN: VTX-214-001-103
Availability:
15 in stock
Original price
£3.72
-
Original price
£3.72
Original price
£3.72
£3.72
£3.72
-
£3.72
Current price
£3.72
The VTX-214-001-103 is a AC-DC power supply featuring a 1W single output producing a 3.3V voltage. The transformer features a compact size suitable for PCB applications with limited space.
Regulated single output Input: 90-265VAC, 47-63Hz (100-370VDC) Output voltage: 3.3VDC Output current: 300mA Low ripple & noise Encapsulated design Safety appovals: EN61558, EN60950, CE
Specification
| Ambient Temperature | 70°C |
| Back Order Lead Time | 7 |
| Input Voltage | 90-265VAC (100-370VDC) |
| MOQ | 1 |
| Output Current | 300mA |
| Output Voltage | 3.3VDC |
| Power Rating | 1W |
