3.3V AC-DC 5W Single Output Power Supply VTX-214-005-103
by Vigortronix
SKU 480338
MPN: VTX-214-005-103
Availability:
Only 4 left!
Original price
£8.06
-
Original price
£8.06
Original price
£8.06
Inc VAT
£8.06
-
£8.06
Current price
£8.06
Inc VAT
The VTX-214-005-103 is a AC-DC power supply featuring a 5W single output producing a 3.3V voltage. The transformer features a compact size suitable for PCB applications with limited space.
Regulated single output Input: 90-265VAC, 47-63Hz (100-370VDC) Output voltage: 3.3VDC Output current: 1272mA Low ripple & noise Encapsulated design Safety appovals: EN61558, EN60950, CE, UL
Specification
| Ambient temperature | 50°C |
| Back order lead time | 5 Days |
| Input voltage | 90-265VAC (100-370VDC) |
| Output current | 1.272A |
| Output voltage | 3.3VDC |
| Power rating | 5W |
