330pF 100V Polypropylene 5mm Capacitor ±2.5% Wima FKP2
by Wima
SKU 482400
MPN: FKP2-330P/100
Availability:
72 in stock
Original price
£0.50
-
Original price
£0.50
Original price
£0.50
Inc VAT
£0.50
-
£0.50
Current price
£0.50
Inc VAT
330pF 100V polypropylene capacitor from the Wima FKP2 series, featuring very low dielectric absorption suitable for high frequency applications including sample and hold, timing, LC-filtering, oscillating circuits and audio equipment.
Pulse duty construction Very low dissipation factor Negative capacitance change versus temperature Terminal pitch: 5mm Body dimensions: 4.5 x 6 x 7.2mm Tolerance: ±2.5% Enclosure material: self-extinguishing, UL94V-0 Maximum operating voltage: 100V DC, 63V AC
Specification
| Back order lead time | 5 Days |
| Capacitance | 330pF |
| Height | 6mm |
| Length | 7.2mm |
| Material | Polypropylene |
| Mounting style | Through Hole |
| Operating temperature | -55°C to +100°C |
| Pitch | 5mm |
| Tolerance | ±2.5% |
| Voltage rating | 63VAC / 100VDC |
| Width | 4.5mm |
