4.7nF 100V Polypropylene 5mm Capacitor ±2.5% Wima FKP2

by Wima
SKU 482405

MPN: FKP2-4.7N/100

Availability:
Out of stock
Sold out
Original price £0.54 - Original price £0.54
Original price
£0.54 Inc VAT
£0.54 - £0.54
Current price £0.54 Inc VAT
4.7nF 100V polypropylene capacitor from the Wima FKP2 series, featuring very low dielectric absorption suitable for high frequency applications including sample and hold, timing, LC-filtering, oscillating circuits and audio equipment.

  • Pulse duty construction
  • Very low dissipation factor
  • Negative capacitance change versus temperature
  • Terminal pitch: 5mm
  • Body dimensions: 5.5 x 7 x 7.2mm
  • Tolerance: ±2.5%
  • Enclosure material: self-extinguishing, UL94V-0
  • Maximum operating voltage: 100V DC, 63V AC
  • Specification
    Back order lead time 5 Days
    Capacitance 4.7nF
    Height 7mm
    Length 7.2mm
    Material Polypropylene
    Mounting style Through Hole
    Operating temperature -55°C to +100°C
    Pitch 5mm
    Tolerance ±2.5%
    Voltage rating 63VAC / 100VDC
    Width 5.5mm
