470nF 63V 5mm Polyester Box Capacitor 10% R82DC3470AA60K

by Kemet
SKU 552106

MPN: R82DC3470AA60K

Availability:
462 in stock
Original price £0.40 - Original price £0.40
Original price
£0.40 Inc VAT
£0.40 - £0.40
Current price £0.40 Inc VAT
470nF 63V polyester capacitor from the R82 series constructed of metallized polyester with radial leads of tinned wire. Radial leads are electrically welded to the contact metal layer on the ends of the capacitor winding. The capacitor is encapsulated with thermosetting resin in a box of material meeting the UL 94V–0 requirements. Typical applications include blocking, coupling, decoupling, timing and oscillator circuits.

  • Pitch: 5mm
  • Tolerance: 10%
  • Self healing
  • Size: 7.2 x 9.5 x 4.5mm
  • Specification
    Back order lead time 5 Days
    Capacitance 470nF
    Height 9.5mm
    Length 7.2mm
    Material Polyester
    Moq 5
    Mounting style Through Hole
    Operating temperature -55°C to +105°C
    Package Box
    Pitch 5mm
    Tolerance ±10%
    Voltage rating 63V
    Width 4.5mm
