47r 10W Aluminium Wirewound Resistor 5%
SKU 483557
MPN:
Availability:
179 in stock
Original price
£1.75
-
Original price
£1.75
Original price
£1.75
Inc VAT
£1.75
-
£1.75
Current price
£1.75
Inc VAT
47r 10W aluminium clad resistors featuring a small package designed for direct heatsink mounting. The resistors are suitable for a wide range of applications including power supplies and audio.
High power to volume Wound to maximise high pulse capability 150V maximum working voltage 5% tolerance Solder terminations Features 2 mounting holes
Specification
| Back order lead time | 45 Days |
| Dimensions | 19 x 21 x 10mm (Length x Width x Height) |
| Maximum operating voltage | 150V |
| Mpn | 483557 |
| Packaging | Bulk |
| Power rating | 10W |
| Resistance | 47Ω |
| Temperature coefficient | ±300ppm/°C |
| Termination | Solder Lug |
| Tolerance | ±5% |
