4k7 7 Commoned Resistor Network 2%

SKU 552263

MPN:

Availability:
325 in stock
Original price £0.14 - Original price £0.14
Original price
£0.14 Inc VAT
£0.14 - £0.14
Current price £0.14 Inc VAT
4k7 thick film 8-pin commoned resistor network featuring 7 resistors housed in a single in-line package, suitable for high density printed circuit boards.

  • Power: 0.125W
  • Tolerance: ±2%
  • Maximum working voltage: 100V
  • Pitch: 2.54mm
  • Specification
    Back Order Lead Time 5 Days
    Circuit Type Commoned
    Maximum Operating Voltage 100V
    MOQ 5
    mpn RNLA08G0472B0E
    Number of Pins 8
    Number of Resistors 7
    Operating Temperature -55°C to +125°C
    Packaging Cut Tape
    Pitch 2.54mm
    Power Rating 0.125W
    Resistance 4.7KΩ
    Temperature Coefficient ±200ppm/°C
    Termination Through Hole
    Tolerance ±2%
