5 Pole JST XH Top Entry Male Connector 2.5mm
SKU 550379
MPN: 550379
Availability:
369 in stock
Original price
£0.13
-
Original price
£0.13
Original price
£0.13
£0.13
-
£0.13
Current price
£0.13
5 way pin header with 2.5mm pitch suitable for connecting wires to PCBs. The headers feature a friction lock to ensure secure retention when mated and are suitable for replacing JST XH connectors.
2.5mm pitch Solder termination Nylon-66 housing Tin plated bronze contacts Rated Current: 3A Rated Voltage: 250V
Specification
Back Order Lead Time | 45 Days |
Contact Material | Tin Plated Phosphor Bronze |
Current Rating | 3A |
Housing Material | PA66 |
MOQ | 5 |
Mounting Type | PCB Mount |
Number of Ways | 5 |
Operating Temperature | -25°C to +85°C |
Pitch | 2.5mm |
Termination Method | Solder |
Voltage Rating | 250VAC |
