5-Way Male Header 2.54mm

SKU 329003

MPN: 329003

Availability:
506 in stock
Original price £0.15 - Original price £0.15
Original price
£0.15
£0.15 - £0.15
Current price £0.15
Single row 2.54mm headers for vertical mounting, suitable for a range of applications including use with PCBs, flat cables etc.

  • Gold plated brass contacts
  • 0.64mm pin diameter
  • Solder termination
  • Pitch: 2.54mm
  • 6mm pin height
  • Can easily be separated
  • Specification
    Back Order Lead Time 30 Days
    Contact Material Gold Plated Brass
    Current Rating 1A
    Housing Material PA6T
    MOQ 5
    Mounting Type PCB Mount
    Number of Pins 5
    Number of Ways 5
    Operating Temperature -40°C to +105°C
    Pitch 2.54mm
    Termination Method Solder
