500K Linear 24mm Mono Potentiometer
SKU 481850
MPN: 481850
Availability:
202 in stock
Original price
£0.94
-
Original price
£0.94
Original price
£0.94
£0.94
-
£0.94
Current price
£0.94
500K mono potentiometer featuring a 24mm diameter base and solder lug terminals, suitable for panel mount applications.
Resistance: 500K Taper: linear Resistance tolerance: ±20% Solder lug terminals 6mm splined shaft Panel cut-out: 8.2mm Shaft length: 12mm Base diameter: 24mm
Specification
| Back Order Lead Time | 45 Days |
| Dimensions | 24mm Diameter |
| Maximum Voltage | 250VAC |
| Mounting Hole Diameter | 8.2mm |
| Mounting Type | Panel Mount |
| Operating Temperature | -20°C to +70°C |
| Power Rating | 0.2W |
| Resistance | 500KΩ |
| Shaft Diameter | 6mm |
| Taper | Linear |
| Termination Type | Solder Lug |
| Tolerance | ±20% |
| Total Rotation | 300° |
