5V AC-DC 10W Single Output Power Supply VTX-214-010-105
by Vigortronix
SKU 480344
MPN: VTX-214-010-105
Availability:
Only 5 left!
Original price
£10.28
-
Original price
£10.28
Original price
£10.28
£10.28
-
£10.28
Current price
£10.28
The VTX-214-010-105 is a AC-DC power supply featuring a 10W single output producing a 5V voltage. The transformer features a compact size suitable for PCB applications with limited space.
Regulated single output Input: 90-265VAC, 47-63Hz (100-370VDC) Output voltage: 5VDC Output current: 2000mA Low ripple & noise Encapsulated design Safety appovals: EN61558, EN60950, CE, UL
Specification
| Ambient Temperature | 70°C |
| Back Order Lead Time | 5 Days |
| Input Voltage | 90-265VAC (100-370VDC) |
| Output Current | 2A |
| Output Voltage | 5VDC |
| Power Rating | 10W |
