5V AC-DC 1W Single Output Power Supply VTX-214-001-105
by Vigortronix
SKU 480329
MPN: VTX-214-001-105
Availability:
7 in stock
Original price
£5.90
-
Original price
£5.90
Original price
£5.90
£5.90
£5.90
-
£5.90
Current price
£5.90
The VTX-214-001-105 is a AC-DC power supply featuring a 1W single output producing a 5V voltage. The transformer features a compact size suitable for PCB applications with limited space.
Regulated single output Input: 90-265VAC, 47-63Hz (100-370VDC) Output voltage: 5VDC Output current: 200mA Low ripple & noise Encapsulated design Safety appovals: EN61558, EN60950, CE
Specification
| Ambient Temperature | 70°C |
| Back Order Lead Time | 5 Days |
| Input Voltage | 90-265VAC (100-370VDC) |
| Output Current | 200mA |
| Output Voltage | 5VDC |
| Power Rating | 1W |
