7046YADB Black Paddle On-On PCB Rocker Switch DPDT 4A 30VDC
by APEM
SKU 487818
MPN: 7046YADB+U612
Availability:
22 in stock
Original price
£7.01
-
Original price
£7.01
Original price
£7.01
£7.95
£7.95
-
£7.95
Current price
£7.95
The 7046YADB is a black paddle PCB rocker switch with a bracket mount and DPDT contacts, suitable for PCB mounting applications.
Black narrow paddle U612 DPDT contacts On-On operation Bracket mounting PCB terminals Epoxy sealed terminals Gold plated silver contacts Rating: 4A 30VDC 4.7mm terminal pitch
Specification
| Actuation | Latching |
| Back Order Lead Time | 10 Days |
| Colour | Black |
| Contact Configuration | DPDT |
| Contact Material | Gold Plated Silver |
| Contact Rating | 4A 30VDC |
| Current Rating | 4A |
| Electrical Life | 50,000 Cycles |
| Illuminated | No |
| Mounting Style | PCB |
| Number of Poles | 2 |
| Number of Positions | 2 |
| Operating Temperature | -40°C to +85°C |
| Pitch | 4.7mm |
| Switch Operation | On-On |
| Terminal Type | PCB |
| Voltage Rating | 30VDC |
