7732CD APEM Black Paddle On-(On) Momentary Panel Mount Rocker Switch SPDT 0.4A 20V
by APEM
SKU 487712
MPN: 7732CD+U492+U543
Availability:
28 in stock
Original price
£7.17
-
Original price
£7.17
Original price
£7.17
£7.17
£7.17
-
£7.17
Current price
£7.17
The 7732CD is a black snap-in rocker switch featuring SPDT contacts, suitable for panel mounting applications.
Black paddle SPDT contacts On-(On) momentary operation Solder lug terminals Gold plated brass contacts Panel thickness: 1 to 2.5mm Panel cut-out: 15 x 12.5mm Rating: 0.4A 20VAC/DC 4.7mm terminal pitch
Specification
| Actuation | Momentary |
| Back Order Lead Time | 10 Days |
| Colour | Black |
| Contact Configuration | SPDT |
| Contact Material | Gold Plated Brass |
| Contact Rating | 0.4A 20VAC/DC |
| Current Rating | 0.4A |
| Electrical Life | 50,000 Cycles |
| Illuminated | No |
| Mounting Style | Panel |
| Number of Poles | 1 |
| Number of Positions | 2 |
| Operating Temperature | -40°C to +85°C |
| Pitch | 4.7mm |
| Switch Operation | On-(On) |
| Terminal Type | Solder |
| Voltage Rating | 20VAC/DC |
