8 Way Standard Blade Fuse Holder Box - Underside Terminals

8 way fuse box suitable for use with standard blade fuses, featuring a transparent cover and gasket, suitable for panel mount applications. The holder features underside 6.3mm blade terminals and fixing holes located at the ends of the box.

8 ways

Colour: black

Transparent clip-on lid

6.3mm male blade terminals

Panel cut-out: 89 x 28mm

M5 fixing hole thread size

103mm fixing hole pitch

Maximum panel thickness: 5mm

Dimensions: 42 x 115 x 30mm (H x W x D)
