90°C Normally Closed Thermostat Thermal Temperature Switch NC

90°C Normally Closed Thermostat Thermal Temperature Switch NC

by Switch Electronics
SKU 481888

MPN: 481888

Availability:
138 in stock
£1.01 - £1.01
£1.01
£1.01 - £1.01
£1.01
90°C automatic reset thermostat switch featuring normally closed contacts and reliable compact design suitable for a wide range of applications.

  • Normally closed contacts
  • Auto reset function
  • Action temperature: 90°C
  • Reset temperature: 75°C
  • 6.3mm quick connect terminals
  • Rating: 10A 250VAC
    • Download Product Data Sheet PDF
    Specification
    Activation Temperature 90°C
    Back Order Lead Time 30 Days
    Contact Configuration NC
    Contact Rating 10A 250VAC
    Current Rating 10A
    Electrical Life 100,000 Cycles
    Mounting Style Panel Mount
    Number of Positions 2
    Opening Temperature 90°C
    Operating Temperature 220°C Max
    Returning Temperature 75°C
    Temperature Tolerance 5°C
    Terminal Type Quick Connect
    Voltage Rating 250VAC
    Request a quote

    Customer Reviews

    Based on 1 review
    100%
    (1)
    0%
    (0)
    0%
    (0)
    0%
    (0)
    0%
    (0)
    A
    Alan Hadfield
    I replace a faulty thermostat in a heater with this

    I replaced a faulty thermostat cut out in a convection heater. It seems to have worked o k .
