Blue 3W Star High Power LED 35lm 135°

SKU 490463

MPN: HP70NBD

Availability:
385 in stock
Original price £0.80 - Original price £0.80
Original price
£0.80
£0.80 - £0.80
Current price £0.80
Blue high power 3W LEDs featuring a high luminous flux, mounted to a heatsink for dissipating heat. The LEDs feature a low profile design with a small package suitable for a range of applications including backlighting, general illumination and indication.

  • Luminous flux: 35lm
  • Wavelength: 470nm
  • Viewing angle: 135°
  • Forward voltage: 3.4V
  • Forward current: 700mA, 1000mA peak
  • Excellent weather resistance
  • Long lifespan
  • Width: 19.9mm (across flats)
  • Height: 6.65mm
  • Specification
    Back Order Lead Time 40 Days
    Colour Blue
    Diameter 8.0mm
    Forward Current 700mA
    Forward Voltage 3.4V
    Lens Colour Clear
    Lens Shape Dome
    Luminous Flux 35lm
    Luminous Intensity 35lm
    MOQ 1
    Mounting Style Surface Mount
    Number of Pins 2
    Operating Temperature -40°C to 85°C
    Package PCB Substrate
    Packaging Bulk
    Power Dissipation 2660mW
    Power Rating 3W
    Viewing Angle 135°
    Wavelength 470nm
