Blue 5mm Water Clear LED 5000mcd 30°

SKU 484966

MPN: LL-504BC2V-B4-2BD

Availability:
424 in stock
Original price £0.14 - Original price £0.14
Original price
£0.14 Inc VAT
£0.14 - £0.14
Current price £0.14 Inc VAT
Blue 5mm LED featuring a clear lens and 5000mcd luminous intensity suitable for applications including use as indicators, backlighting and illumination.

  • Luminous intensity: 5000mcd
  • Wavelength: 470nm
  • Viewing angle: 30°
  • Forward voltage: 3.2V
  • Forward current: 25mA
  • Suitable for through-hole mounting
  • Cathode identified as the shorter lead
  • 2.54mm lead pitch
  • Clear lens
  • Excellent weather resistance
  • Long lifespan
  • Specification
    Back order lead time 5 Days
    Colour Blue
    Diameter 5mm
    Forward current 25mA
    Forward voltage 3.2V
    Lens colour Clear
    Lens shape Round
    Luminous intensity 5000mcd
    Mode Constant
    Moq 5
    Mounting style Through Hole
    Number of pins 2
    Operating temperature -40°C to +80°C
    Package 5mm
    Packaging Bulk
    Power dissipation 90mW
    Viewing angle 30°
    Wavelength 470nm
