BTA06-600BRG Isolated Triac 6A 600V
by ST
SKU 551832
MPN: BTA06-600BRG
Availability:
7 in stock
Original price
£1.22
-
Original price
£1.22
Original price
£1.22
Inc VAT
£1.22
-
£1.22
Current price
£1.22
Inc VAT
The BTA06 triac series is suitable for general purpose AC switching. They can be used as an ON/OFF function in applications such as static relays, heating regulation, induction motor starting circuits, or for phase control operation in light dimmers, motor speed controllers etc. By using an internal ceramic pad, the BTA series provides voltage insulated tab (rated at 2500VRMS) complying with UL standards.
Type: Standard Peak Off-State Voltage: 600V Peak On-State Current: 6A Gate Trigger Current: 50mA Gate Trigger Voltage: 1.3V
Specification
| Back order lead time | 5 Days |
| Gate trigger current | 50mA |
| Hold current | 50mA |
| Mounting type | Through Hole |
| Off state voltage | 600V |
| On state current | 6A |
| Package | TO-220AB |
| Single or array | Single |
| Surge current | 60A |
| Type | Standard |
