BTA08-600TWRG Isolated Triac 8A 600V

by ST
SKU 551839

MPN: BTA08-600TWRG

Availability:
9 in stock
Original price £1.32 - Original price £1.32
Original price
£1.32 Inc VAT
£1.32 - £1.32
Current price £1.32 Inc VAT
The BTA08 triac series is suitable for general purpose AC switching. They can be used as an ON/OFF function in applications such as static relays, heating regulation, induction motor starting circuits, or for phase control operation in light dimmers, motor speed controllers etc. By using an internal ceramic pad, the BTA series provides voltage insulated tab (rated at 2500VRMS) complying with UL standards.

  • Type: Sensitive Gate
  • Peak Off-State Voltage: 600V
  • Peak On-State Current: 8A
  • Gate Trigger Current: 5mA
  • Gate Trigger Voltage: 1.3V
  • Specification
    Back order lead time 5 Days
    Gate trigger current 5mA
    Hold current 10mA
    Mounting type Through Hole
    Off state voltage 600V
    On state current 8A
    Package TO-220AB
    Single or array Single
    Surge current 80A
    Type Sensitive Gate
