BTA41-600BRG Isolated Triac 40A 600V
by ST
SKU 551848
MPN: BTA41-600BRG
Availability:
17 in stock
Original price
£4.71
-
Original price
£4.71
Original price
£4.71
£4.71
£4.71
-
£4.71
Current price
£4.71
The BTA41 Triac series are suitable for general purpose mains power AC switching. ON/OFF or phase angle function in applications such as static relays, light dimmers and appliance motors speed controllers.
High current triac Low thermal resistance with clip bonding High commutation (4Q) or very high commutation (3Q) capability Type: Standard Peak Off-State Voltage: 600V Peak On-State Current: 40A Gate Trigger Current: 50mA Gate Trigger Voltage: 1.3V
Specification
| back order lead time | 5 |
| Gate Trigger Current | 50mA |
| Hold Current | 80mA |
| MOQ | 1 |
| Mounting Type | Through Hole |
| Off State Voltage | 600V |
| On State Current | 40A |
| Package | TOP3 |
| Single or Array | Single |
| Surge Current | 400A |
| Type | Standard |
