DB107 Bridge Rectifier Diode 1A 1000V DIL-4

SKU 552220

MPN: DB107

Availability:
30 in stock
Original price £0.40 - Original price £0.40
Original price
£0.40 Inc VAT
£0.40 - £0.40
Current price £0.40 Inc VAT
DB107 bridge rectifier diode featuring 1A average forward current and 1000V repetitive peak reverse voltage, housed in a flame retardant UL 94V-0 package. Suitable for printed circuit board applications.

  • Excellent for automation insertion
  • 50A surge overload rating
  • Ideal for printed circuit boards
  • Glass passivated junction
  • Specification
    Average rectified current 1A
    Back order lead time 5 Days
    Maximum dc blocking voltage 1000V
    Maximum forward voltage 1.1V
    Maximum rms voltage 700V
    Moq 5
    Mounting style Through Hole
    Operating temperature -65°C to 150°C
    Package DB-1
    Packaging Tube
    Peak reverse voltage 1000V
    Peak surge current 50A
