Green 5mm Concave Water Clear LED 460mcd 100°

SKU 485811

MPN: LL-504PGC2K-G5-2C

Availability:
397 in stock
Original price £0.19 - Original price £0.19
Original price
£0.19 Inc VAT
£0.19 - £0.19
Current price £0.19 Inc VAT
Green 5mm concave LED featuring a water clear package and 460mcd luminous intensity suitable for applications including use as indicators, backlighting and illumination.

  • Luminous intensity: 460mcd
  • Wavelength: 525nm
  • Viewing angle: 100°
  • Forward voltage: 3.2V
  • Forward current: 25mA
  • Suitable for through-hole mounting
  • Cathode identified as the shorter lead
  • 2.54mm lead pitch
  • Water clear lens
  • Excellent weather resistance
  • Long lifespan
  • Specification
    Back order lead time 40 Days
    Colour Green
    Diameter 5mm
    Forward current 25mA
    Forward voltage 3.2V
    Lens colour Clear
    Lens shape Concave
    Luminous intensity 460mcd
    Mode Constant
    Moq 5
    Mounting style Through Hole
    Number of pins 2
    Operating temperature -40°C to +85°C
    Package 5mm
    Packaging Bulk
    Power dissipation 95mW
    Viewing angle 100°
    Wavelength 525nm
