HG2J-7UT22TF-B 7" Capacitive Touch Screen Display TFT LCD IDEC
by IDEC
SKU 493029
MPN: HG2J-7UT22TF-B
Availability:
Only 2 left!
Original price
£294.20
-
Original price
£294.20
Original price
£294.20
£294.20
£294.20
-
£294.20
Current price
£294.20
The HG2J-7UT22TF-B is a stylish smart touch displays with an input voltage of 12-24V DC make the HG2J HMI a leading choice for applications across a variety of industries, including industrial, solar, and vehicle applications. Offered in a popular size form factor, HG2J delivers a technologically advanced display with projected-capacitive (PCAP) technology to provide a slimmer and sleeker appearance, small installation footprint, improved performance, and longer life.
800 x 480 High Resolution 50,000 Hours Backlight Life 500 cd/m² Brightness -20 to +60˚C Extreme Operating Temperature IP66/67F, Type 4X, 12, 13, and Class I Div 2 approval ratings Remote Access, FTP, Email, Mobile, App and Custom Web Page Support 4 protocols simultaneously 3-year Warranty
Specification
| Back Order Lead Time | 120 Days |
| Colour | Black |
| Depth | 30.4mm |
| Display Resolution | 800x480 |
| Display Size | 7-Inch |
| Display Type | TFT |
| Height | 128mm |
| MOQ | 1 |
| Operating Temperature | -20°C to +60°C |
| Panel Thickness | 1-5mm |
| Protection Level | IP66F / IP67F |
| Rated Voltage | 12-24VDC |
| Voltage Range | 10.2-28.8VDC |
| Width | 186mm |
