IDEC 22mm 3 Position Maintained Selector Switch 3NC IP65 YW1S-3E03

SKU 931886

MPN: YW1S-3E03

49 in stock
Original price £14.44 - Original price £14.44
Original price
£14.44 Inc VAT
£14.44 - £14.44
Current price £14.44 Inc VAT
The YW1S-3E03 is a 3 position maintained selector switch from the YW series manufactured by IDEC. The switch features a heavy-duty rugged construction and is suitable for standard 22mm panel cut-outs for industrial applications.

  • 3NC contacts
  • Voltage rating: 600V
  • Current rating: 10A
  • 22mm panel cut-out
  • 27.6mm knob diameter
  • IP65 protection rating
  • Self cleaning contacts
  • Interchangeable switch components
  • Dimensions: 69.8 x 30 x 41.4mm (length x width x height)
  • Specification
    Actuation Maintained
    Back order lead time 10 Days
    Contact configuration 3NC
    Contact rating 2A 380V, 6A 240V
    Current rating 10A
    Electrical life 100,000 Cycles
    Head type Selector
    Illuminated No
    Illumination colour Amber
    Key index angle 45°
    Mounting style Panel
    Number of positions 3
    Operating temperature -20°C to +55°C
    Panel cut out 22.3mm
    Panel thickness 0.8-6mm
    Product series YW
    Protection level IP65
    Rated thermal current 10A
    Terminal type Screw
    Voltage rating 600V
