KBPC802 Bridge Rectifier Diode 8A 200V
SKU 552227
MPN: KBPC802
Availability:
43 in stock
Original price
£1.06
-
Original price
£1.06
Original price
£1.06
£1.06
£1.06
-
£1.06
Current price
£1.06
KBPC802 miniature bridge rectifier diode featuring 8A average forward current and 200V repetitive peak reverse voltage, housed in a flame retardant UL 94V-0 plastic case suitable for mounting to printed circuit boards.
125A surge overload rating Low forward voltage drop Moulded plastic package Dimensions: 19.0mm x 19.0mm x 7.0mm (Width x Length x Height) Pitch: 12.7mm x 12.7mm
Specification
| Average Rectified Current | 8A |
| Back Order Lead Time | 7 |
| Body Dimensions | 19.0mm x 19.0mm x 7.0mm (Width x Length x Height) |
| Maximum DC Blocking Voltage | 200V |
| Maximum Forward Voltage | 1.1V |
| Maximum RMS Voltage | 140V |
| MOQ | 1 |
| Mounting Style | Through Hole |
| Operating Temperature | -55°C to 125°C |
| Package | KBPC-8/10 |
| Packaging | Bulk |
| Peak Reverse Voltage | 200V |
| Peak Surge Current | 125A |
