(On)-Off-(On) Mini Toggle Switch DPDT
SKU 112026
MPN: 112026
Availability:
19 in stock
Original price
£1.21
-
Original price
£1.21
Original price
£1.21
£1.21
£1.21
-
£1.21
Current price
£1.21
Miniature size toggle switches with a momentary action suitable for a wide range of applications.
(On)-Off-(On) action DPDT contacts Switch returns to the center when released 6mm panel cut-out Solder terminals Secured with nut Rating: 3A 250VAC, 6A 125VAC Dimensions: 3.3 x 13.2 x 12.7mm (Height x Width x Length) Maximum Panel Thickness: 3mm
Specification
| Actuation | Momentary |
| Back Order Lead Time | 45 Days |
| Contact Configuration | DPDT |
| Contact Rating | 3A 250VAC |
| Current Rating | 3A |
| Electrical Life | 10,000 Cycles |
| Illuminated | No |
| Mounting Style | Panel |
| Number of Poles | 2 |
| Number of Positions | 3 |
| Operating Temperature | -25°C to +85°C |
| Panel Cut Out | 6mm |
| Switch Operation | (On)-Off-(On) |
| Terminal Type | Solder |
| Voltage Rating | 250VAC |
