On-On Black Rectangle Rocker Switch SPDT
SKU 130022
MPN: 130022
Availability:
161 in stock
Original price
£0.58
-
Original price
£0.58
Original price
£0.58
£0.58
£0.58
-
£0.58
Current price
£0.58
Rectangle rocker switch with SPDT contacts and on-on action. The switch is designed for snap-in mounting and is suitable for a wide range of applications.
On-on action SPDT contacts 4.8mm quick connect terminals Panel cut-out: 19.2 x 13mm Dimensions: 25 x 21 x 15mm (Height x Length x Width) Maximum current: 6A Maximum voltage: 250VAC
Specification
| Actuation | Latching |
| Back Order Lead Time | 45 |
| Contact Configuration | SPDT |
| Contact Rating | 6A 250VAC |
| Current Rating | 6A |
| Electrical Life | 10,000 Cycles |
| Illuminated | No |
| MOQ | 1 |
| Mounting Style | Panel |
| Number of Poles | 1 |
| Number of Positions | 2 |
| Operating Temperature | -25°C to +85°C |
| Panel Cut Out | 19.2 x 13mm |
| Switch Operation | On-On |
| Terminal Type | Quick Connect |
| Voltage Rating | 250VAC |
